Non-contact thickness gauge
A non-contact measurement device for ink thickness measurement is launched. The spectral confocal displacement sensor is equipped with a high-precision imported slide table, with a resolution of up to the nanometer level. It can stably measure thickness, height difference, roughness, waviness, profile, and flatness.
Keywords:
Electronics and Electrical Engineering
Product Attachments:
Retail Price
Market Price
Weight
Category:
Remaining Stock
隐藏域元素占位
- Product Description
-
- Commodity name: Non-contact thickness gauge
A non-contact measurement device for ink thickness measurement is launched. The spectral confocal displacement sensor is equipped with a high-precision imported slide table, with a resolution of up to the nanometer level. It can stably measure thickness, height difference, roughness, waviness, profile, and flatness.
Product Introduction:
A non-contact measurement device for ink thickness measurement. Equipped with a high-precision imported slide and a spectral confocal displacement sensor. The highest resolution can reach the nanometer level. It can stably measure thickness, height difference, roughness, waviness,
profile, and flatness.
Product Features:
● Ultra-high resolution, up to the nanometer level;
● One-click automatic measurement, automatically identifies and measures thickness and height difference;
● Stable measurement on glass, ceramic, and high-gloss metal surfaces;
● Non-contact measurement, applicable in both wet and dry states;
● Customizable platform to meet different size detection needs;
● Can measure thickness, height difference, width, roughness, waviness, profile, and flatness.
Technical Parameters:
Probe Installation Distance 11-19mm Scanning Range 50mm Measurement Speed Adjustable 2μm-100μm Probe Measurement Range 400μm-4mm Measurement Accuracy ±0.025%F.S. Resolution 0.01μm (400μm range)
