MZ4RT Differential Interference Contrast Microscope
The MZ4RT is a state-of-the-art inspection microscope featuring clear imaging, a long working distance, ease of use, and a rich application software suite. It is a cost-effective microscope ideal for semiconductor and microelectronics industries and research, offering performance comparable to imported brands.
Keywords:
Photoelectric detection equipment
Optical detection equipment
Electronics and Electrical Engineering
Product Attachments:
Retail Price
Market Price
Weight
Category:
Remaining Stock
隐藏域元素占位
- Product Description
-
- Commodity name: MZ4RT Differential Interference Contrast Microscope
The MZ4RT is a state-of-the-art inspection microscope featuring clear imaging, a long working distance, ease of use, and a rich application software suite. It is a cost-effective microscope ideal for semiconductor and microelectronics industries and research, offering performance comparable to imported brands.
I. Usage 【 Usage 】
MZ4RT It is the latest inspection microscope, featuring clear imaging, long working distance, ease of use, and rich application software. It is a cost-effective microscope for semiconductor and microelectronics industries and research, and its performance is comparable to imported brands.
It is comparable to imported brands in performance.
II. Features【Characteristic】
1) Infinity-corrected optical system, higher light efficiency, using high-brightness LED light source, providing excellent image quality
2) A variety of highly functional accessories can meet various inspection needs and can be used for bright field, polarized light, and differential interference observation.
III. Meets Multiple Application Needs Simultaneously
5X ITO Wires, TP Module Detection
10X Conductive Particle Indentation 20X Conductive Particle Burst Shape IV. Technical Parameters【Technical Parameter】
Model Number
MZ4RT Differential Interference Microscope
Optical System
CSIC Infinity-corrected Optical System
Main
Unit
Observation Method
Bright Field / Differential Interference / Polarized Light
Illumination System
Bright Field LED Lamp illumination, Koehler illumination system, with aperture diaphragm, field diaphragm, with lifting device, 360 Degree inspection device
Focusing System
Coaxial coarse and fine adjustment ， Minimum fine adjustment scale 1 Micron ， Maximum sample height: 33mm
Turret
Bright field three-hole centring with DIC Slot
Observation Tube
Trinocular observation tube (splitting ratio 100:0/80:20 ), 0.5XCTV Interface
DIC Differential Interference
DICR
Large field eyepiece
PL10X (Field number: 20 )
Objective
5X
10X
20X
50X ( Optional, price 2000 Yuan)
Stage
280x200mm Two-dimensional mechanical moving platform
Industrial Camera
HDMI Color Camera
21 Inch HDMI Monitor
Measurement Software
Professional measurement software
